Modular Aluminum Stage Truss for Events 500kg Capacity
| Herkunftsort | Jiangsu, China |
|---|---|
| Markenname | Shizhan |
| Modellnummer | Aluminium Truss-Rt |
| Min Bestellmenge | 100 |
| Preis | $44-46 |
Treten Sie mit mir für freie Proben und Kupons in Verbindung.
whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
Wenn Sie irgendein Interesse haben, leisten wir 24-stündige Online-Hilfe.
xProduktdetails
| Verbindungsart | Pin-Verbindung | Belastbarkeit | 500 kg |
|---|---|---|---|
| Material | Aluminiumlegierung | Einheitslänge | 0.5m, 1m, 2m, 3m, 4m, 5m oder besonders angefertigt |
| Fachwerkform | Quadrat, Dreieck, Runde oder besonders angefertigt | Form des Truss-Abschnitts | Quadratisch oder rund |
| Dicke der Binderrohr | 1,5/2/3mm | Truss -Rohrdurchmesser | 20 mm, 32 mm, 50 mm |
| Härte | 16 Grad | Leichter Duty Fachwerk | 200*200mm; 250*250mm |
| Mittelstufe Fachwerk | 290*290 mm, 300*300 mm; 350*350 mm, 300*400 mm; 400*400 mm; 450*450 mm; 400*600 mm | Schwerlastschrauben | 520*760 mm; 600*760 mm; 600*1000 mm |
| Hauptrohrdicke | 30*2 mm; 50*3mm; 50*4mm; 50*5mm | Vizerohrdicke | 18*2mm; 20*2,5mm; 25*2,5mm |
| Dicke der Klammerrohr | 20*2mm; 25*2mm; 30*2mm | ||
| Hervorheben | modular aluminum stage truss,aluminum lighting truss 500kg capacity,event truss with high load capacity |
||
Produkt-Beschreibung
Aluminium Stage Truss Structure Outdoor Stage Truss Design
Product Specifications
| Attribute | Value |
|---|---|
| Connection Type | Pin Connection |
| Feature | Durable |
| Frame design | Modular |
| Product Type | Display Truss |
| Application | Events, Concert, Music, Performance, DJ Band, Event, Exhibition |
| Welding | Welding |
| Load-bearing Capacity | 500kg |
| Assembly Method | Quick installation |
| Structure Type | Modular Structure |
| Material | Aluminum alloy |
| Unit length | 0.5m, 1m, 2m, 3m, 4m, 5m or customized |
| Color | Silver, black or customized |
| Truss section shape | Square or round |
| Shape | Square, Triangle, round or customized |
| Truss tube thickness | 1.5/2/3MM |
| Truss tube diameter | 20mm, 32mm, 50mm |
| Hardness | 16 degree |
Technical Details
Truss Material: Aluminum alloy 6082-T6
Light duty truss: 200*200mm; 250*250mm
Medium duty truss: 290*290mm, 300*300mm; 350*350mm; 300*400mm; 400*400mm; 450*450mm; 400*600mm
Heavy duty truss: 520*760mm; 600*760mm; 600*1000mm
Main tube thickness: 30*2mm; 50*3mm; 50*4mm; 50*5mm
Vice tube thickness: 18*2mm; 20*2.5mm; 25*2.5mm
Brace tube thickness: 20*2mm; 25*2mm; 30*2mm
Length: 0.5m/1m/1.5m/2m...4m or custom size
Truss type: Spigot or bolt
Truss Shape: Ladder truss, triangular truss, square truss, arch truss, circle truss
Color: Silver or black, blue, green...
Usage: Concert, new product release, fashion show, booth stand construction
Delivery Time: 10 working days
Applications
Our aluminum alloy stage truss is a modular system made of lightweight aluminum alloy tubes that can be easily assembled and disassembled. It is widely used in various events and applications:
- Concerts and festivals: Build stages for concerts, festivals, and outdoor events with configurable shapes and sizes
- Theatrical productions: Construct sets, backdrops, and structures for plays, musicals, and operas
- Exhibitions and trade shows: Create booths, displays, and exhibition structures
- Corporate events: Build stages and backdrops for product launches, conferences, and award ceremonies
- Sports events: Construct race start/finish lines, podiums, and scoreboards
Why Choose Our Products
- TUV, SGS, CE Certified products
- 15 years experience in truss, stage, barrier and scaffolding
- 35,000 m² workshop with excellent production capacity
- Professional engineering team for perfect project solutions
- Own aluminum profile production line for quality control
- Strict QC process with installation test before delivery
Frequently Asked Questions
How do I know your quality? Our products have TUV/SGS/CE/ISO9001 certificates and we offer samples for quality checking.
Payment methods: T/T, Western Union, Trade Assurance, L/C.
Warranty: 1 year warranty with free replacement for non-artificial damage.
Customization: Our technical team offers perfect solutions for custom projects.
